Urban L1³ – meeting box for 4 people

1. Improved acoustics & sound insulation

• optimized multi-layer wall structure
• further improved sound absorption in the interior
• Significantly quieter conversation atmosphere even in meetings with several people
• ideal for meetings, video conferences and hybrid meetings

Result: less background noise, high speech intelligibility for all participants

2. Significantly quieter and more efficient ventilation

• newly developed ventilation system
• even airflow throughout the interior
• complete air exchange approximately every 2 minutes
• Extremely quiet operation – even during longer meetings

Result: fresh air without noticeable fan noise

3. Higher quality materials & sturdier construction

• Aluminum frame ≥ 1.5mm
• additional powder-coated steel panels (1.0mm)
• More precise processing of all components
• high stability with clear, modern lines

Result: durable, robust, professional – even with intensive use

4. New design & configuration options

• new exterior colors
• new interior colors for acoustic panels
• selectable Frame shapes (square, round, flattened)
• clear, modular option logic

Result: optimal integration into modern office and room concepts

5. Smart Plus Glass – thought ahead

• continue 32 ± 3 dB sound insulation
• noticeably improved acoustics
• optional with switchable smart glass
• Privacy at your fingertips
• ideal for sensitive meetings

Result: maximum flexibility with consistently high acoustic performance

6. Barrier-free meeting boxes – Urban-Line 3rd generation

• barrier-free designs within the for the first time Urban Line – 3rd generation
• optimized for Level access and comfortable use with a wheelchair
• Interpretation according to the central requirements of DIN 18040
• available as
  • M1³ barrier-free
  • L1³ barrier-free
  • L2³ barrier-free
• developed for inclusive, sustainable working environments

Result: Barrier-free use with the full acoustics, technology and design quality of the Urban Line

*Note on DIN 18040:
The M1³ barrier-free and L1³ barrier-free is based on the specifications of DIN 18040, but differs due to the compact design Door lights and turning surface from the full DIN dimensions, but in practice it can be used for wheelchairs.
The L2³ barrier-free Fully meets the requirements of DIN 18040, including door passage and free turning area.

Dimensions

• Outside: 2150 × 1350 × 2185mm
• Inside: 2003 × 1202 × 2005mm

Weight

• Closed back wall (acoustic panel): 540kg
• Split back wall (acoustic panel + glass): 512kg
• 2x glass wall (front & back): 480kg

Sound insulation

• Plus: 32 ± 3dB
• SmartPlus: 32 ± 3 dB (with switchable smart glass)

Glass

• 6 mm ESG safety glass

Lighting

• integrated LED ceiling light
• 5000K (neutral white)
• Presence sensor

Ventilation

• fully automatic ventilation system
• complete air exchange approximately every 2 minutes

Power & connections

• 110-220V/50Hz
• integrated USB system (12 V)

Guarantee

• 5 years on frame & construction
• 1 year on electrical & interior

Option: table & seating

• fixed table (standard for the Urban-Line)
  • Table for closed or divided back wall
  • Table for glass back wall
• Seating depending on configuration
  • Classic sofa
  • modern sofa
• comfortable for meetings with up to 4 people
• suitable for longer meetings

Note: The price shown does not include interior fittings. This can be supplemented individually.

Exterior colors

• White
• Black
• Petrol
• Lemon yellow
• Red

Interior colors – acoustic panels

• Silver gray (standard)
• Grey
• Red
• Orange
• Yellow
• Light brown

(Please specify the desired interior color when requesting a quote/ordering. This option cannot currently be selected as a variant in the shop. The standard is “silver gray”)

floor

• Carpet in Anthracite

Glass options

• Plus – 32 ± 3dB
• SmartPlus – 32 ± 3 dB with switchable smart glass

Wall configuration

• Closed back wall
  Maximum sound insulation, quiet and shielded feeling of space.
• Split rear wall (glass + acoustics)
  Very high sound insulation with a more open feeling of space.
• 2× glass wall (front & back)
  Maximum transparency and brightness, open feeling of space, slightly lower sound insulation than with a closed back wall.

Frame shape

• Square (standard)
• Round
• Flattened

(Please specify the desired frame shape when requesting a quote/ordering. This option cannot currently be selected as a variant in the shop. The standard is “square”.)

• Meetings in open space
• Team meetings
• Video conferencing
• Hybrid meetings
• Retreat for concentrated group work
